HE-150U-T-W

150m HDMI Wallplate Transmitter

Taska HE-150U-T-W is an innovative 86×86mm wall plate extender that integrates both HDMI and USB-C input interfaces. It leverages  an optimized version of HDBaseT technology. It is designed to transmit high-definition audio/video, along with bi-directional IR, RS-232, and CEC control signals over a single CAT6 cable for distances up to 150 meters. Supporting ultra-high definition up to 4K2K@60Hz (4:4:4), comprehensive advanced audio, and HDR formats, it also features bi-directional PoC. This multifunctional extender is the ideal all-in-one solution for video conferencing, multimedia teaching, and digital signage applications.


  • PRODUCT FEATURES
  • SPECIFICATION
  • DOWNLOADS
  • Compliant with HDMI 2.0b and HDCP 2.2 Standards: Ensures high-quality video transmission and content protection
  • Dual HDMI and USB-C Inputs: Supports automatic and manual switching modes
  • Supports Video Resolution up to 4K@60Hz 4:4:4: Delivers ultra-high-definition video output with support for HDR, HDR10, HDR10+,Dolby Vision, and HLG
  • Long-Distance Transmission: Signal can be extended up to 150 meters (1080P@60Hz) and 120 meters (4K@60Hz 4:4:4) using a single CAT6/6a cable
  • Bidirectional PoC Functionality: The transmitter or receiver can be powered from either end, eliminating the need for additional power supplies
  • Standard UK Size Wall Plate Design: Compact 86x86mm design, ideal for wall mounting

Datasheet

  • HE-150U-T-W_Datasheet
