AM-44D

4x4 Dante Digital Audio Processor

The Taska AM-44D is a professional audio processing system based on the ADI SHARC platform with a semi-open architecture,designed for high-end audio applications. It delivers 24-bit/48kHz audio quality and incorporates core technologies including independent Adaptive Feedback Suppression (AFS), full-duplex Adaptive Echo Cancellation (AEC), Active Noise Control (ANC),Gain-sharing Automatic Mixer Control (AMC), and Automatic Gain Control (AGC).

The system is integrated with Dante and can be easily integrated into the Dante ecosystem. It also features a flexible 4x4 audio matrix with up to 8 customizable presets and channel duplication/linking/grouping capabilities, it adapts to diverse audio management requirements. The system supports centralized control via RS-232 and UDP, programmable wall panels, and includes a built-in dual-channel USB audio interface for conferencing and recording applications. It also supports both PoE+ and 12V DC power supply.

  • PRODUCT FEATURES
  • SPECIFICATION
  • DOWNLOADS
  • ADI SHARC platform with semi-open architecture
  • Integrated management of multiple devices offers open user interface and supports good sound quality (at 24bit/48kHz.)
  • Each channel has its own independent adaptive feedback suppression which can find and suppress audio feedback automatically
  • Full-duplex Adaptive Echo Cancellation (AEC) and Active Noise Cancellation (ANC)
  • Gain sharing Auto Mixer Control (AMC)
  • Automatic Gain Control (AGC)
  • Support Dante audio
  • Full-featured audio mixing matrix supports adjustable input level
  • Provides up to 8 presets, each can work independently
  • Supports audio channel duplicating, linking, and groupin
  • Supports RS-232 and UDP central control.
  • Provides the flexibility to assign UDP port number, with the control commands available through the contral software
  • Works with 2 types of our wall panel products, both software programmable.
  • Built-in dual channel USB sound card can be used for audio recording, audio broadcasting, and video conference
  • Supports both PoE+ power supply and DC 12V power adapter

Datasheet

  • AM-44D_Datasheet
