HUMX88ARC 8x8 HDMI Matrix Switcher is a high-performance AV signal management device designed for modern multimedia environments. It supports the transmission of video up to 4K@60Hz (RGB/YCbCr 4:4:4) and multi-channel Hi-Res digital audio from 8 HDMI sources to 8 HDMI displays. Compliant with HDMI 2.0b and HDCP 2.2 standards, the device supports high-definition audio formats such as LPCM 7.1ch, Dolby TrueHD, and DTS-HD Master Audio, and features Audio Breakout functionality, allowing HDMI audio to be extracted and output via coaxial or analog audio ports.
The HUMX88ARC supports fast switching, video scaling (4K to 2K), built-in equalization, signal shaping, and driving functions, ensuring stable and high-quality signal transmission. Equipped with intelligent EDID management, users can copy EDID from any output or set customized EDID to ensure signal compatibility, avoiding display issues caused by EDID mismatches.
Additionally, the device supports ARC (Audio Return Channel) functionality, allowing audio from display devices to be sent back to the matrix, further simplifying audio system integration. Users can easily control and configure the device via TCP/IP, RS-232 serial commands, Web GUI, front panel buttons, and IR remote, making it ideal for meeting rooms, command & control centers, multimedia showrooms, and more.
PRODUCT FEATURES
SPECIFICATION
DOWNLOADS
High-Definition Video Transmission: Supports 4K@60Hz (RGB/YCbCr 4:4:4) video resolution, compliant with HDMI 2.0b and HDCP 2.2 standards
Multi-Channel Audio Support: Supports high-definition audio formats such as LPCM 7.1ch, Dolby TrueHD, and DTS-HD Master Audio
Audio Breakout Functionality: Extracts HDMI audio and outputs via coaxial or analog audio ports
Intelligent EDID Management: Users can copy EDID from any output or set customized EDID to ensure signal compatibility
ARC Functionality: Supports Audio Return Channel, simplifying audio system integration
Fast Switching & Video Scaling: Supports fast switching and 4K to 2K video scaling
Signal Enhancement Technology: Built-in equalization, signal shaping, and driving functions ensure stable signal transmission
Multiple Control Options: Control via TCP/IP, RS-232 serial commands, Web GUI, front panel buttons, and IR remote
