OmniFrame88

8x8 Seamless Modular Matrix

The OmniFrame88 is a compact 8x8 HD seamless hybrid matrix designed for small to medium-sized meeting rooms, multimedia training rooms, and exhibition applications. It supports 8 inputs and 8 outputs, compatible with HDMI, DVI, VGA, SDI, HDBaseT, and fiber optic signals input, and supports up to 4K@60Hz resolution. Equipped with dual power supply redundancy and main control board as standard to ensure stable operation of the system.

PRODUCT FEATURES
SPECIFICATION
DOWNLOADS

Card Frame Features

Modular Design: Supports various input and output boards for flexible configuration to meet different application scenarios
High reliability: Dual power supply redundancy design supports 7x24 hours uninterrupted operation
Control Board : Supports RS-232, LAN & Web GUI control for easy system integration, also support front panel button operation and IR control
Seamless Switching: Supports seamless switching with no black screen or flickering during transitions
High-Resolution Support: Supports 2K and 4K resolutions, meeting high-definition and ultra-high-definition video signal processing needs

Input Board Features

Multiple Signal Inputs: Supports HDMI, DVI, VGA, SDI, HDBaseT, and fiber optic inputs
High Bandwidth Support: Supports up to 18Gbps data transfer rate, ensuring uncompressed and lossless signal transmission
Audio Embedding: Supports audio embedding for synchronized audio signal transmission

Output Board Features

Support Popular Signal Outputs: Supports HDMI & HDBaseT outputs
High-Resolution Support: Supports 2K and 4K resolutions, meeting high-definition and ultra-high-definition display needs
Audio De-embedding: Supports audio de-embedding for independent audio signal output
