HUMX88SL

8x8 4K30 Seamless HDMI Matrix Switcher

The HUMX88SL is a high-performance 8x8 HDMI seamless matrix switcher supporting 4K@30Hz resolution, designed for professional multi-source and multi-display applications. It features seamless switching, video wall splicing, EDID management, and multiple control options (front panel, IR remote, RS-232, and Web GUI). Equipped with an analog audio output port, it synchronously outputs extracted audio signals following the OUTPUT HD1 interface. All 8 HDMI outputs support independent brightness and contrast adjustment, making it ideal for meeting rooms, command & control centers, multimedia showrooms, control rooms, and more.

PRODUCT FEATURES
SPECIFICATION
DOWNLOADS

Seamless Switching Function: No black screen or interruption during source switching, ideal for applications requiring frequent changes of source
Video Wall: Supports 4x2, 2x2, 1x8, and other layouts for multi-screen displays
EDID Management: 9 preset EDID modes with custom and copy-from-output options
Resolution Adjustment: Independent output resolution settings (up to 4K@30Hz)
Multiple Controls: Front panel, IR remote, RS-232 and Web GUI
Audio Breakout: The analog audio output port synchronously outputs extracted audio signals following the OUTPUT HD1 interface
